APS73 UL Certified 40~65W SMPS 12V 5A 4A 3A Desktop Switching Power Supply 18V 24V AC/DC Adapter
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Input Range: | 100 ~ 240Vac, 50 / 60Hz | Power Range: | 40 ~ 65W |
|---|---|---|---|
| Certificate: | UL/cUL, FCC, CB, GS, CE, TUV, PSE, KC, KCC, SAA, RCM, UKCA | Application: | Consumer Electronic Devices · Telecommunication Devices · Office Facilities · Industrial Equipments |
| MTBF: | ＞100,000 Hours | Size: | 105.5L X 46.4W X 28.3H (mm) |
APS73 UL Certified 40~65W SMPS 12V 5A 4A 3A Desktop Switching Power Supply 18V 24V AC/DC Adapter
APS73 is a 40~65W compact size highly reliable Desktop style single-output green adaptor series, which is compact and convenient for carry. APS73 is a class II power unit, accepting the input range from 100VAC to 240VAC. The whole series provides different models with output voltages ranging between 5VDC and 56VDC that it can satisfy the demands for various types of consumer electronic devices.
APS73 is compliant with the lastest U.S energy regulation EISA 2007/DOE(Level VI), EU ErP and CoC version 5. The supreme feature allows the adaptor to save the energy when it is under either the operating mode or the standby mode. The entire series is approved for international safety regulations; moreover, it adopts the 94V-0 flame retardant plastic case that it can effectively prevent users from electric hazards.
1, LPS Compliance
2, AC input power suitable for the world
3, Meet DOE/CEC/ERP Level VI
4, Over voltage, over current, short circuit and over load protection
5, Per pieces adapter is 100% full load -burn in test (4 hours)
6, All the products have passed the full load test process aging
7, Low interference & noise
8, Standard: EN/IEC 62368, EN/IEC 61558, EN/IEC 60601 or EN/IEC 61347
9, Certification: UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA
| Input Range | 100 to 240Vac, 50/60Hz |
| Power Range | 40~65W max |
| Output Range | 12 ~ 56V / 900mA ~ 5.0A |
| Protection | Over load protection |
| Over voltage protection | |
| Short circuit protection | |
| Safety Approvals | GS CE ROSH CB UL cUL FCC KC PSE SAA |
| Standard | EN/IEC 62368, EN/IEC 61558, EN/IEC 61347, EN/IEC 60601 for your selection |
| Efficiency | Level VI |
| AC plug | EU / US / UK / AU and Others for your selection |
| Standard DC Connector | 5.5*2.5 / 5.5*2.1 /5.5*1.7 / 4.8*1.7 / 4.0*1.7 / 3.5*1.35 / 6.3*3.0 with pin inside |
| Operating Temperature Range | 0--40°C |
| Storage Temperature Range | -20 --- 85°C |
| High Humidity Operation | + 40 °C and 90 ~ 95% Humidity |
| Net weight | About 300g per unit |
| MTBF | 100,000 hours |
| Application | Consumer Electronic Devices · Telecommunication Devices · Office Facilities · Industrial Equipments |
| Packing | PE bag + Carton or White Box + Carton or As your Request |
| MODEL No. | MAX. OUTPUT POWER (W) |
OUTPUT VOLTAGE (Vo) |
MIN. LOAD (Io) |
MAX. LOAD (Io) |
LOAD REGULATION |
LINE REGULATION |
RIPPLE & NOISE |
|||||
| APS73A | 40W | 12~18V | 0A | 3.33A | ± 5% | ± 1% | 240mV | |||||
| APS73B | 40W | 19~24V | 0A | 2.1A | ± 5% | ± 1% | 360mV | |||||
| APS73C | 40W | 32~42V | 0A | 1.25A | ± 5% | ± 1% | 630mV | |||||
| APS73D | 40W | 44~56V | 0A | 0.9A | ± 5% | ± 1% | 840mV | |||||
| APS73E | 50W | 12~18V | 0A | 4.16A | ± 5% | ± 1% | 240mV | |||||
| APS73F | 50W | 19~24V | 0A | 2.63A | ± 5% | ± 1% | 360mV | |||||
| APS73G | 50W | 32~42V | 0A | 1.56A | ± 5% | ± 1% | 630mV | |||||
| APS73H | 50W | 44~56V | 0A | 1.13A | ± 5% | ± 1% | 840mV | |||||
| APS73J | 60W | 12~18V | 0A | 5A | ± 5% | ± 1% | 240mV | |||||
| APS73K | 60W | 19~24V | 0A | 3.15A | ± 5% | ± 1% | 360mV | |||||
| APS73L | 60W | 32~42V | 0A | 1.87A | ± 5% | ± 1% | 630mV | |||||
| APS73M | 60W | 44~56V | 0A | 1.36A | ± 5% | ± 1% | 840mV | |||||
| APS73N | 65W | 12~18V | 0A | 5.41A | ± 5% | ± 1% | 240mV | |||||
| APS73P | 65W | 19~24V | 0A | 3.42A | ± 5% | ± 1% | 360mV | |||||
| APS73Q | 65W | 32~42V | 0A | 2.03A | ± 5% | ± 1% | 630mV | |||||
| APS73R | 65W | 44~56V | 0A | 1.47A | ± 5% | ± 1% | 840mV | |||||
