36W Max 12V 24V 36V Desktop AC-DC Power Adapter | IEC 62368/61558 Certified

En/IEC/UL 62368/ 61558 Standard 16~36W Switching Power Supply 12V 2A 3A AC DC Adapter 24V 1A 1.5A Desktop Transformer with UL FCC CE

APS24 is a 16~36W compact size highly reliable Desktop style single-output green adaptor series, which is compact and convenient for carry. APS24 is a class II power unit, accepting the input range from 100VAC to 240VAC. The whole series provides different models with output voltages ranging between 5VDC and 48VDC that it can satisfy the demands for various types of consumer electronic devices.

APS24 is compliant with the lastest U.S energy regulation EISA 2007/DOE(Level VI), EU ErP and CoC version 5. The supreme feature allows the adaptor to save the energy when it is under either the operating mode or the standby mode. The entire series is approved for international safety regulations; moreover, it adopts the 94V-0 flame retardant plastic case that it can effectively prevent users from electric hazards.​

1, Extreme small and space-saving, takes up one spot on power strip
2, AC input power suitable for the world
3, Meet DOE/CEC/ERP Level VI
4, Over voltage, over current, short circuit and over load protection
5, Per pieces adapter is 100% full load -burn in test (4 hours)
6, All the products have passed the full load test process aging
7, Low interference & noise
8, Standard: EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347
9, Certification: UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA

MODEL No.		MAX. OUTPUT POWER (W)		OUTPUT VOLTAGE (Vo)	MIN. LOAD (Io)	MAX. LOAD (Io)		LOAD REGULATION		LINE REGULATION	RIPPLE & NOISE
APS24A		16W		5~8V	0A	2A		± 5%		± 1%	100mV
APS24B		20W		5~8V	0A	3A		± 5%		± 1%	100mV
APS24C		24W		5~8V	0A	4A		± 5%		± 1%	100mV
APS24D		18W		9~11V	0A	1.5A		± 5%		± 1%	250mV
APS24E		24W		9~11V	0A	2A		± 5%		± 1%	250mV
APS24F		27W		9~11V	0A	3A		± 5%		± 1%	250mV
APS24G		20W		12~17V	0A	1.66A		± 5%		± 1%	250mV
APS24H		30W		12~17V	0A	2.5A		± 5%		± 1%	250mV
APS24J		24W		18~24V	0A	1.33A		± 5%		± 1%	350mV
APS24K		30W		18~24V	0A	1.66A		± 5%		± 1%	350mV
APS24M		20W		36~48V	0A	0.55A		± 5%		± 1%	480mV
APS24N		30W		36~48V	0A	0.83A		± 5%		± 1%	480mV
APS24P		36W		12V	0A	3A		± 5%		± 1%	250mV
APS24Q		24W		12V	0A	2A		± 5%		± 1%	250mV
APS24R		36W		24V	0A	1.5A		± 5%		± 1%	350mV
