APS330 EN/UL 62368 330W Max 24V 48V Desktop Switching Power Supply 12V 56V AC DC Adapter
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Input Range: | 100 ~ 240Vac, 50 / 60Hz | Power Range: | 300 ~ 330W |
|---|---|---|---|
| Certificate: | UL/cUL, FCC, CB, GS, CE, TUV, PSE, KC, KCC, SAA, RCM, UKCA | Application: | Consumer Electronic Devices · Telecommunication Devices · Office Facilities · Industrial Equipments |
| MTBF: | ＞100,000 Hours | Case Size: | 200L X 100W X 29H (mm) |
APS330 EN/UL 62368 330W Max 24V 48V Desktop Switching Power Supply 12V 56V AC DC Adapter
APS330 is a 240~330W compact size highly reliable Desktop style single-output green adaptor series, which is compact and convenient for carry. APS330 is a class II power unit, accepting the input range from 100VAC to 240VAC. The whole series provides different models with output voltages ranging between 12VDC and 56VDC that it can satisfy the demands for various types of consumer electronic devices.
APS330 is compliant with the lastest U.S energy regulation EISA 2007/DOE(Level VI), EU ErP and CoC version 5. The supreme feature allows the adaptor to save the energy when it is under either the operating mode or the standby mode. The entire series is approved for international safety regulations; moreover, it adopts the 94V-0 flame retardant plastic case that it can effectively prevent users from electric hazards.
1, LPS Compliance
2, AC input power suitable for the world
3, Energy Efficiency Level VI or CoC Tier II
4, Over voltage, over current, short circuit and over load protection
5, Per pieces adapter is 100% full load -burn in test (4 hours)
6, All the products have passed the full load test process aging
7, Low interference & noise
8, Standard: EN/IEC 62368, EN/IEC 61558, EN/IEC 60601 or EN/IEC 61347
9, Certification: UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA
| Input Range | 100 ~ 240Vac, 50/60Hz |
| Power Range | 300~330W max |
| Output Range | 12 ~ 56V / 5.89A ~ 25A |
| Protection | Over load protection |
| Over voltage protection | |
| Short circuit protection | |
| Safety Approvals | UL/CUL, FCC, CE, GS, TUV, CB, RCM, SAA, PSE, KC, UKCA |
| Standard | EN/IEC 62368 / 61347 / 61558 / 60601 for your selection |
| Efficiency | Level VI |
| AC plug | EU / US / UK / AU and Others for your selection |
| Standard DC Connector | 5.5*2.5 / 5.5*2.1 /5.5*1.7 / 4.8*1.7 / 4.0*1.7 / 3.5*1.35 / 6.3*3.0 with pin inside |
| Operating Temperature Range | 0--40°C |
| Storage Temperature Range | -20 --- 85°C |
| High Humidity Operation | + 40 °C and 90 ~ 95% Humidity |
| Net weight | About 1200g per unit |
| MTBF | 100,000 hours |
| Application | Consumer Electronic Devices · Telecommunication Devices · Office Facilities · Industrial Equipments |
| Packing | PE bag + Carton or White Box + Carton or As your Request |
| MODEL No. | MAX. OUTPUT POWER (W) |
OUTPUT VOLTAGE (Vo) |
MIN. LOAD (Io) |
MAX. LOAD (Io) |
LOAD REGULATION |
LINE REGULATION |
RIPPLE & NOISE |
||||
| APS330A | 240W | 12~16V | 0A | 20A | ± 5% | ± 1% | 240mV | ||||
| APS330B | 240W | 19~24V | 0A | 12.63A | ± 5% | ± 1% | 360mv | ||||
| APS330C | 240W | 32~42V | 0A | 7.5A | ± 5% | ± 1% | 630mv | ||||
| APS330D | 240W | 48~56V | 0A | 5A | ± 5% | ± 1% | 840mV | ||||
| APS330E | 270W | 12~16V | 0A | 22.5A | ± 5% | ± 1% | 240mV | ||||
| APS330F | 270W | 19~24V | 0A | 14.21A | ± 5% | ± 1% | 360mv | ||||
| APS330G | 270W | 32~42V | 0A | 8.43A | ± 5% | ± 1% | 630mv | ||||
| APS330H | 270W | 48~56V | 0A | 5.62A | ± 5% | ± 1% | 840mV | ||||
| APS330J | 300W | 12~16V | 0A | 25A | ± 5% | ± 1% | 240mV | ||||
| APS330K | 300W | 19~24V | 0A | 15.78A | ± 5% | ± 1% | 360mv | ||||
| APS330L | 300W | 32~42V | 0A | 9.37A | ± 5% | ± 1% | 630mv | ||||
| APS330M | 300W | 48~56V | 0A | 6.25A | ± 5% | ± 1% | 840mV | ||||
| APS330N | 330W | 19~24V | 0A | 17.36A | ± 5% | ± 1% | 360mv | ||||
| APS330P | 330W | 32~42V | 0A | 10.31A | ± 5% | ± 1% | 630mv | ||||
| APS330Q | 330W | 48~56V | 0A | 6.87A | ± 5% | ± 1% | 840mV | ||||
