EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer

China EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer supplier
EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer supplier EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer supplier EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer supplier EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer supplier EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer supplier

Large Image :  EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer

Product Details:

Place of Origin: Shenzhen
Brand Name: ANENpower
Certification: UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Model Number: APM05E

Payment & Shipping Terms:

Minimum Order Quantity: 500pcs
Price: Please contact our Sales
Packaging Details: PE bag / White box / Custom made
Delivery Time: 18~25 working days after receiving the deposit
Payment Terms: 50% deposit, 50% before dispatch
Supply Ability: 500,000.00pcs/month
Detailed Product Description
Input: 100 ~ 240Vac, 50 / 60Hz Power Range: 4.5 ~ 6W
Certificates: UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA Application: Breath Detectors/testers, ECG, EEG, Portable Medical Devices, Medical Tablets, Digital Blood Pressure Monitors, Etc.
MTBF: 100,000 Calculated Hours Case Size: 53L X 41W X 36H

EN/IEC 60601 certified 6W Max 5V Medical AC Adapter 9V Switching Power Supply 12V Transformer


The APM05E series is a family of wall mount Medical AC adapters (wall adapters/wall warts) equipped with EU plug that are designed to offer 6W continuous output power with a single output of either 5V, 12V, or 24V (coming with a universal input of 100~240 Vac).

APM05E are burn-in test conducted and offer class II operation, low leakage current, over load protection (OLP), crowbar mode over voltage protection (OVP), and 2 x MOPP (Means of Patient Protection) classification to ensure the safety of the patient, caregiver, and device to which the power supply is applied. The series owns comprehensive protection designs along with all-inclusive safety certifications and conforms to major international safety standards including IEC/EN 60601-1. All modules are fully compliant with the Level VI efficiency standard and RoHS directive.

APM05E switching power supplies are designed for medical applications and are ideal for breath detectors/testers, ECG, EEG, portable medical devices, medical tablets, digital blood pressure monitors, etc.



• 2 x MOPP Compliance, IEC/EN60601-1 Approval
• LPS Compliance
• Protections: Short circuit / Over voltage / Over current
• Energy Efficiency Level VI
• No Load Power Consumption ≤ 0.1W
• MTBF > 100,000 hours

• Power Range: 6W
• Universal AC Input 100~240 VAC
• Frequency: 50~60Hz
• AC Plug type: U:USA, C: China, E:EU, K:UK, A: SAA, S: South Africa
• Output voltage available from 5~24 VDC
• Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
• All models meet RoHS and WEEE
• Dimension(L x W x H): 53L x 41W x 36H
• Weight: 70grams



Model NO. MAX OUTPUT POWER OUTPUT VOLTAGE MIN LOAD MAX LOAD LOAD REGULATION LINE REGULATION RIPPLE & NOISE
APM05EA 6W 5-18V 0A 1.2A ±5% ±1% 100mV
APM05EB 6W 9-12V 0A 0.66A ±5% ±1% 180mV
APM05EC 4.5W 9V 0A 0.5A ±5% ±1% 180mV
APM05ED 6W 9V 0A 0.67A ±5% ±1% 180mV
