UL 60601 Certified Medical Power Adapter 5V 2.4A 12V US Plug for Infusion Pumps Syringe Drivers
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Input Range: | 100 ~ 240Vac, 50 / 60Hz | Power Range: | 12W Max |
|---|---|---|---|
| Certificates: | UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA | Application: | Breath Detectors/testers, ECG, EEG, Portable Medical Devices, Medical Tablets, Digital Blood Pressure Monitors, Etc. |
| MTBF: | 100,000 Calculated Hours | Case Size: | 55L X 27W X 55H (mm) |
UL 60601 Certified Medical Power Adapter 5V 2.4A 12V US Plug for Infusion Pumps Syringe Drivers
UL 60601 certified medical-grade power adapter delivering precise 5V 2.4A and 12V output with US plug for critical infusion therapy equipment. Engineered specifically for hospital-grade infusion pumps and syringe drivers requiring uninterrupted power delivery in clinical environments. This safety-certified adapter features medical isolation barriers, over-current protection, and electromagnetic compatibility to prevent interference with sensitive drug delivery systems. Designed for 24/7 operation in hospitals, clinics, and home healthcare settings where power stability directly impacts patient treatment accuracy and medication administration safety. Compact form factor with thermal protection ensures reliable performance for life-critical infusion devices while meeting stringent UL 60601 medical safety standards and FCC electromagnetic compliance requirements.
• Power Range: 12W
• Universal AC Input 100~240 VAC
• Frequency: 50~60Hz
• AC Plug type: U:USA, E:EU, K:UK, A: AU
• Output voltage available from 5~24 VDC
• 2 x MOPP Compliance, IEC/EN60601-1 Approval
• LPS Compliance
• Protections: Short circuit / Over voltage / Over current
• Energy Efficiency Level VI
• No Load Power Consumption ≤ 0.1W
• MTBF > 100,000 hours
• Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
• All models meet RoHS and WEEE
• Dimension(L x W x H): 55L x 27W x 55H (mm)
• Weight: 70g
| Model NO. | MAX OUTPUT POWER | OUTPUT VOLTAGE | MIN LOAD | MAX LOAD | LOAD REGULATION | LINE REGULATION | RIPPLE & NOISE |
| APM12UA | 12W | 5-8V | 0A | 2.4A | ±5% | ±1% | 100mV |
| APM12UB | 12W | 9-11V | 0A | 1.33A | ±5% | ±1% | 180mV |
| APM12UC | 12W | 12-17V | 0A | 1.0A | ±5% | ±1% | 250mV |
| APM12UD | 12W | 18-24V | 0A | 0.66A | ±5% | ±1% | 350mV |
