230W Medical Desktop AC Adapter 24V 9.58A 19V 12.1A Power Supply for Advanced Medical Device

230W Max Medical Desktop AC Adapter: 24V 9.58A / 19V 12.1A Ultra-Safe Power Solution

Product Overview

The 230W Max Medical Desktop AC Adapter is a high-performance, clinical-grade power conversion unit engineered for the heavy-duty energy requirements of next-generation medical systems. Delivering a robust 24V 9.58A or a massive 19V 12.1A, this adapter is the premier power choice for High-End Surgical Systems, Advanced Diagnostic Imaging, and Integrated Medical Workstations.

Strictly compliant with global medical safety standards (IEC 60601-1), it features reinforced insulation and an ultra-low leakage current architecture to ensure maximum safety for both patients and clinical operators. The desktop form factor provides a secure, grounded connection that effectively suppresses electromagnetic interference (EMI), ensuring that high-speed medical processors and sensitive diagnostic sensors operate with absolute precision and data integrity. Whether integrated into a robotic surgical suite or a high-throughput laboratory analyzer, this 230W unit delivers the sustained power and medical-grade protection required for mission-critical healthcare.

Key Specifications

Our medical series incorporates redundant safety layers and advanced thermal management to ensure fail-safe performance in 24/7 clinical environments.

• Input Voltage: 100-240V AC, 50/60Hz (Universal Global Compliance).

• Total Output Power: 230W Continuous Maximum.

• Common Output Configurations:

  • 19V/19.5V Series: 19V 12.1A / 19.5V 11.8A (230W Max - For high-end medical PCs)

  • 24V Series: 24V 9.58A (230W Max - Standard for clinical automation and actuators)

  • 12V Series: 12V 19.1A (230W Max - Ultra-high current for multi-rail logic)

  • 48V Series: 48V 4.8A (230W Max)

• Medical Safety Compliance: Fully compliant with IEC/EN/ANSI/AAMI ES 60601-1 (3.1 Edition).

• Isolation Protection: 2 x MOPP (Means of Patient Protection) for superior electrical isolation.

• Leakage Current: Ultra-low leakage current (< 100µA) to prevent micro-shocks in patient-proximity areas.

• AC Inlet: IEC320-C14 (Grounded Class I for maximum EMI shielding).

• Efficiency: Meets DoE Level VI and CoC Tier 2 energy efficiency standards.

• MTBF (Reliability): > 100,000 Hours, ensuring multi-year clinical uptime.

• Global Certifications: UL/cUL (Medical), CE (MDR), TUV-GS, CB, FCC, RoHS, REACH.

Ideal Applications

The 230W medical-grade output is optimized for high-performance diagnostic and therapeutic electronics:

• Advanced Medical Devices: Robotic surgical assistants, automated operating tables, and surgical navigation systems.

• High-End Imaging: Portable CT/X-ray processing units, 4K/8K surgical displays, and high-performance ultrasound consoles.

• Clinical Computing: Medical-grade AI diagnostic servers, mobile nursing workstations-on-wheels (WOW), and laboratory automation hubs.

• Therapy Systems: High-power therapeutic lasers and advanced life-support ventilators.

• Laboratory Automation: High-throughput blood analyzers and precision DNA sequencing platforms.

Professional Safety Suite

• Reinforced 2 x MOPP Isolation: High-voltage 4000VAC primary-to-secondary isolation for absolute patient protection during invasive procedures.

• Clinical-Grade EMI/EMC: Optimized to prevent interference with wireless hospital infrastructure (WLAN) and high-frequency surgical tools.

• Anti-Bacterial & Flame-Retardant Casing: UL94 V-0 rated high-impact housing, designed to withstand frequent disinfection with clinical-grade chemical agents.

• Ultra-High Current DC Connection: Equipped with 4-Pin Power DIN or High-Current Aviation Connectors to safely manage 12A+ currents without terminal overheating or voltage drop.

• Comprehensive Protection: Active OVP, OCP, and SCP with intelligent auto-recovery to maintain device operation during electrical transients.
