UL60601 Certified 5V 2A 12V 24V Medical Power Adapter AU Plug for Diagnostic Imaging Equipment Clinical Stability
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Input: | 100 ~ 240Vac, 50 / 60Hz | Power Range: | 4.5 ~ 6W |
|---|---|---|---|
| Certificates: | UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA | Application: | Breath Detectors/testers, ECG, EEG, Portable Medical Devices, Medical Tablets, Digital Blood Pressure Monitors, Etc. |
| MTBF: | 100,000 Calculated Hours | Case Size: | 55L X 27W X 55H (mm) |
UL60601 Certified 5V 2A 12V 24V Medical Power Adapter UL Plug for Diagnostic Imaging Equipment Clinical Stability
UL60601 certified medical-grade power adapter with triple output configuration: 5V 2A USB port, 12V AC adapter, and 24V USB charger featuring Australian plug compatibility for critical diagnostic imaging systems. Engineered specifically for clinical environments where power stability is non-negotiable, this medical power supply delivers uninterrupted operation for sensitive imaging equipment including X-ray machines, ultrasound systems, MRI accessories, and portable diagnostic devices. Built with hospital-grade isolation barriers, over-voltage protection, and electromagnetic compatibility shielding to prevent interference with precision medical instruments. The AU plug design meets Australian electrical safety standards while providing thermal protection and voltage regulation for 24/7 clinical operation. Ideal for hospitals, radiology centers, and medical facilities requiring certified reliable power that maintains equipment calibration and imaging accuracy during critical diagnostic procedures where power fluctuations could compromise patient diagnostics and clinical outcomes.
• Power Range: 4.5~6W
• Universal AC Input 100~240 VAC
• Frequency: 50~60Hz
• AC Plug type: U:USA, E:EU, K:UK, A: AU
• Output voltage available from 5~18 VDC
• 2 x MOPP Compliance, IEC/EN60601-1 Approval
• LPS Compliance
• Protections: Short circuit / Over voltage / Over current
• Energy Efficiency Level VI
• No Load Power Consumption ≤ 0.1W
• MTBF > 100,000 hours
• Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
• All models meet RoHS and WEEE
• Dimension(L x W x H): 55L x 27W x 55H (mm)
• Weight: 70g
| Model NO. | MAX OUTPUT POWER | OUTPUT VOLTAGE | MIN LOAD | MAX LOAD | LOAD REGULATION | LINE REGULATION | RIPPLE & NOISE |
| APM05UA | 6W | 5-18V | 0A | 1.2A | ±5% | ±1% | 100mV |
| APM05UB | 6W | 9-12V | 0A | 0.66A | ±5% | ±1% | 180mV |
| APM05UC | 4.5W | 9V | 0A | 0.5A | ±5% | ±1% | 180mV |
| APM05UD | 6W | 9V | 0A | 0.67A | ±5% | ±1% | 180mV |
