72W 12V 5A 6A / 24V 2.5A 3A SAA RCM Certified Switching Power Adapter | AU Plug 36V 48V SMPS Power Supply
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Input: | 100 ~ 240V AC , 50/60Hz | Output Power: | 2W Max |
|---|---|---|---|
| Output Range: | 5 ~ 48V / 1000mA ~ 6000mA | Safety Approvals: | UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA |
| Standard: | EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347 | Warranty: | 3~5 Years |
| AC Plug: | EU / US / UK / AU And Others For Your Selection | Application: | Consumer Electronic Devices · Telecommunication Devices · Office Facilities · Industrial Equipments |
72W 12V 5A 6A / 24V 2.5A 3A SAA RCM Certified Switching Power Adapter | AU Plug 36V 48V SMPS Power Supply
The 72W 12V 5A 6A / 24V 2.5A 3A BIS Certified Switching Power Adapter is a high-performance power solution tailored for various electronic devices in India. Offering flexible output options of 12V (5A or 6A) and 24V (2.5A or 3A), along with support for 36V and 48V, this adapter is designed to meet diverse power requirements efficiently.
- Power Output: 12V 5A, 12V 6A, 24V 2.5A, 24V 3A, 36V, 48V
- Certification: BIS certified, ensuring compliance with Indian safety and quality standards
- Plug Type: India plug, suitable for Indian electrical systems
- Technology: Advanced SMPS (Switch Mode Power Supply) for superior energy efficiency
- Safety: Includes built-in protections against over-current, over-voltage, and short circuits
Compact and durable, this adapter is perfect for powering devices like LED lighting, security systems, and various electronics. With its robust design and BIS certification, it ensures reliable performance and safety for all your power needs in the Indian market.
| Datasheet | |
| Input: | 100 to 240V AC , 50 / 60Hz |
| Output power: | 72W max |
| Output Range: | 5 ~ 48V / 1000mA ~ 6000mA |
| Protection: | Over load protection |
| Over voltage protection | |
| Short circuit protection | |
| Safety Approvals: | UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA |
| Standard: | EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347 |
| Efficiency: | Compliant with the lastest U.S energy regulation EISA 2007/DOE(Level VI), EU ErP and CoC version 5 |
| AC plug: | EU / US / UK / AU and Others for your selection |
| Standard DC Connector: | 5.5*2.5 / 5.5*2.1 /5.5*1.7 / 4.8*1.7 / 4.0*1.7 / 3.5*1.35 / 6.3*3.0 with pin inside |
| Operating Temperature Range: | 0--40°C |
| Storage Temperature Range: | -20 --- 85°C |
| High Humidity Operation: | + 40 °C and 90 ~ 95% Humidity |
| MTBF: | 50,000 hours |
| Application: | Consumer electronic devices · Telecommunication devices · Office facilities · Industrial equipments |
| Packing: | PE bag + Carton or White Box + Carton or As your Request |
