Input Range: | 100 ~ 240VAC , 50 / 60Hz | Output Power: | 6W Max |
---|---|---|---|
Output Range: | 4.2 ~ 14.5V / 0.4 ~ 1.2A | Warranty: | 3~5 Years |
Certificates: | Complied With UL 1310, CSA C22.2 No. 107.2-01, EN/IEC 60335-1/EN IEC 60335-2-29, FCC Part 15B, CE EMC(EN 55014-1+EN 55014-2) | Applications: | Power And Gardening Tools, Small Home Appliances, E-bikes, Or E-scooters, Etc. |
6W Max JP Plug PSE Certified 4.2V 6V 8.4V Lithium / Lead-Acid Battery Charger 12.6V 14.5V Power Supply
APB06J battery chargers for sealed Lithium / Lead acid batteries specifically designed for the personal electric vehicle and robot markets. They are based on switchmode technology, which makes them more efficient and smaller than the old fashioned transformer chargers, and are microprocessor controlled to make them very accurate. These may be left on the battery indefinitely to gently maintain the battery at full charge. This battery chargers enables the highly efficient charging operation of Li-Ion batteries used in applications such as power and gardening tools, small home appliances, e-bikes, or e-scooters at a competitive cost.
1, Lithium / Lead-Acid Battery Charger
2, Constant Power Charging Mode
3, Battery Polarity Reverse Protection
4, LED Charging Indicator
5, Step Fast Charging Capability
6, Protections: Short circuit / Over voltage / Over current / Over temperature
7, MTBF > 50,000 hours
8, Recommend for Lithium / Lead-Acid Battery
Datasheet |
|
Input Range: | 100 ~ 240V AC , 50 / 60Hz |
Regular Output parameters: | 4.2V 0.5A, 4.2V 1A, 4.2V 1.2A, 8.4V 0.5A, 8.4V 0.6A, 6V 0.6A, 12V 0.4A, 14.5V 0.4A, 12.6V 0.5A... |
Output Range: | 4.2~14.5V / 0.4~1.2A |
Charge Mode: | CC (Pre-charge)--CC (Bulk)--CV--Cut off |
Charge status: | Red / Green Indicator light |
Protection: | Over load protection |
Over voltage protection | |
Short circuit protection | |
Certificate: | Complied with UL 1310, CSA C22.2 No. 107.2-01, EN/IEC 60335-1/EN IEC 60335-2-29, FCC Part 15B, CE EMC(EN 55014-1+EN 55014-2) |
Efficiency: | Level VI |
AC plug: | EU / US / UK / AU and Others for your selection |
Standard DC Connector: | 5.5*2.5 / 5.5*2.1 /5.5*1.7 / 4.8*1.7 / 4.0*1.7 / 3.5*1.35 / 6.3*3.0 with pin inside |
Operating Temperature Range: | 0--40°C |
Storage Temperature Range: | -20 --- 85°C |
High Humidity Operation: | + 40 °C and 90 ~ 95% Humidity |
Size: | 29*80*76mm |
MTBF: | 50,000 hours |
Application: | Power and gardening tools, small home appliances, e-bikes, or e-scooters, etc. |
Packing: | PE bag + Carton or White Box + Carton or As your Request |
